    Galvanized 358 Anti Climb Welded Mesh Making Machine

    Ask Lasest Price
    Brand Name : Tianke
    Model Number : TK-HWJ2000
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 15 sets/Month
    Delivery Time : 10 work days
    • Product Details
    • Company Profile

    Galvanized 358 Anti Climb Welded Mesh Making Machine

    Galvanized Wire Mesh High Security 358 Anti Climb Fence Mesh Welding Machine


    Fence Mesh Welding Machine Description

    The fence mesh welding machine is full automatic.The machine is CNC welding machine.There are visual touch screen in the control panel.This is the heart of the control system.The worker can operate the machine just input data in the screen.After input the data,the worker needs to put weft wire to the weft wire hopper and then run the machine.The machine will weld automatically.After the mesh is cut to panels,the worker needs to pick it up and tie it.The machine will weld and cut automatically. The workload of the workers is very small.

    .

    Fence Mesh Welding Machine Advantage

    1. Panasonic/Schneider electric components and visual touch screen;

    2. "V" type slot tunnel, suitable for different wire diameter, no need adjustment.

    3. 600mm2 upper copper wires, much more than before, much easier for electric conduction.

    4. The cross wires should be put into the hopper manually, then fall automatically.It is equipped with SMC (Japan) air cylinder.

    5. Pneumatic welding. The welding electrodes are controlled by SMC (Japan) air cylinders.30*30*30mm, water cooling electrode base.

    6. Cast water-cooling transformers, One transformer control 4 welding electrodes.The welding degree is adjusted by PLC.


    Fence Mesh Welding Machine Parameter

    Name of CommodityFence Mesh Welding Machine
    Wire Diameter3-6mm
    Mesh Size50-300mm
    Mesh Width2000mm
    Mesh LengthAdjustable
    Power4kw
    Warp Wire FeedingCoil Wire
    Weft Wire FeedingPre straightening and cutting wire
    ControlCNC PLC and visual touch screen
    Transformer125kva*3 sets
    Voltage3 phase 380V / 220V / 440V / 415V
    Overall Dimension16*2.7*1.6m
    Weight4000kg
    Warranty12 months
    Oversea ServiceSupport

    Main Welding Machine with control system


    Copper Material: We use high quality copper material for the machine welding electrodes,transformer loops.


    Control system: The visual touch screen is just like a computer.Easy to operate.


    Mesh Pulling System: It is controlled by servo motor and air cylinders.It can pull the mesh in smooth speed.


    Automatic Mesh Cutting Machine:This device can cut the mesh to panels in different length.


    Finish Mesh
