    Single Wire 30M Chain Link Fence Machine 100mm Diamond Mesh Making Machine

    Ask Lasest Price
    Brand Name : Tianke
    Model Number : TK-GHJ-S2000
    Payment Terms : Western Union, T/T, L/C
    Supply Ability : 25 sets/month
    Delivery Time : 5 work days
    • Product Details
    • Company Profile

    Single Wire 30M Chain Link Fence Machine 100mm Diamond Mesh Making Machine

    Single Wire Diamond Green Mesh Fence Chain Link Fence Machine


    Chain Link Fence Machine Description

    This type of machine adopts a single-sided spiral into the wire to weave the wire mesh. And equipped with automatic locking edge and automatic roll net system. Easy to operate and debug.This machine is popular in India.


    Chain Link Fence Machine Advantage

    1. Chain link Fence machine can weave chain link fence in different size. The wire is taken in from the payoff stand and passed through the dies where the diamond size takes place. After passing from the die the diamond pattern wire is automatically thrown on the winding shaft in the stitch process. Once the stitching is complete the woven is manually glided down to enable the next stitch to take place.

    2. The machine is controlled by PLC control system with visual touch screen, so one person can operate two machines.

    3. The chain link fence is automatically wound to form rolls,this is convenient for transport.

    4. The flexible and soft structure, corrosion and rust resistance surface, architectural colors, and easy installation features, all these make the chain link fencing more and more popular all over the world.


    Chain Link Fence Machine Parameter


    ModelSingle WireDouble
    Wire diameter1.3-4mm1.5-4mm
    Mesh size20-100mm25-100mm
    Mesh width0.5-4m0.5-4m
    Speed70-80m²/h120-180m²/h
    Mould Dies4 sets mould for free
    Mesh length30m, adjustable freely as your request
    Mesh sideKnuckled and twisted, or knuckle, or twisted
    Raw materialGalvanized wire, PVC coated wire, etc.
    Machine size4.2*2.2*1.7m6.7*1.43*1.8m
    Weight2500kg4200kg
    OperationOne person can operate two or three machines

    Double wire Chain Link Fence Machine Display


    Wire Mould

    The chain link fence can be weaved into different diamond mesh size by different wire dies.One machine is equipped with 4 dies for free.


    Chain Link Fence Automatic locking device

    The Chain Link need to be locked the tow edges after finishing weave by the main machine.The automatic locking device can implement three types of automatic locking: twisted edge,knuckled edge, twisted and knuckled edge.


    Automatic roll netting device

    After the edges are locked,the chain link fence needs to make to rolls.The rolls is easy to transport.


    Chain Link Fence Factory details


    Finish Fence and Application
