Automatic Single Twist Barb In Border Barbed Wire Making Machine
Barbed Wire Making Machine Description
This machine is full automatic.The core wire and the barb wire is
feeding by wire coils.The machine is driven by gears with low
noise.
Barbed Wire Making Machine Advantages
1. Manually installation, Easy to set up;
2. Steel cover on the driving shaft for safe operation;
3. Saving materials and high capacity;
4. Counter to count the number of barbs and calculate the length of
barbed wire.
5. Button switches and leveler to start and stop the machine
easily.
6. Quick and easy roll extraction from the machine.
7. Guiding system to avoid wire snarls.
Barbed Wire Making Machine Parameter
| Model | CS-A | CS-B | CS-C |
| Motor Power | 3KW | 2.2KW | 2.2KW |
Main Drive Shaft Speed | 402r/min | 355r/min | 355r/min |
Core Wire Diameter | 2.2-3.0mm | 2.2-3.0mm | 1.6-2.8mm |
Barbed Wire Diameter | 1.8-2.2mm | 1.8-2.2mm | 1.6-2.2mm |
| Barb Space | 76mm(3” )/102mm(4” )/127(5”) | 102mm(4” )/127(5”) | 102mm(4” )/127(5”) |
| Twisted Number | 3.5 pieces | 4 pieces | 7 pieces |
| Theoretical Output | 70kg/h | 40kg/h | 40kg/h |
| Weight | 1200kg | 1000kg | 1000kg |
| Dimension | 1950*950*1300mm 1760*550*760mm | 3100*1000*1150mm
| 3100*1000*1150mm
|
Barbed Wire Making Machine Service
Pre-sale service
1. Select equipment model.
2. Design and manufacture products according to clients' special
requirement.
Services during the sale
1. Pre-check and accept products ahead of delivery.
2. Help clients to draft solving plans.
After-sale service
1. We will reply you for your inquiry in 24 hours.
2. After you get the products, we'll send technicians to your
factory. Then they will guide your workers to install and debug the
machine patiently untill the machine can work normally. Since our
factory established, our after-sale team had been to many countries
and received customers' critical acclaim.
Company Introduction
Anping Tianke Wire Mesh Equipment Co.,Ltd. is located at the
junction of Beijing, Tianjin, Shijiazhuang---- Anping County, which
is famous as “Hometown of wire mesh”. The factory is a professional
manufacturer for wire mesh machinery. The factory has been
developing smoothly and quickly based on rich experience and strong
technical personnel.
Our main products: Reinforcing mesh welding machine, fence mesh
welding machine, construction mesh welding machine, automatic mesh
welding machine,chain link fence machine, barbed wire machine,
razor barbed wire machine, expanded metal mesh machine, wire
straightening and cutting machine, wire drawing machine, wire
bending machine and so on.
We have built good reputation among our customers with excellent
quality products, reliable service and good credit. We supply a
whole-process service from product designing, developing,
producing, installing and after-sales services. The company has
been titled” Credible and Reliable Product & Service Supplier” by
numerous users.
We sincerely look forward to your cooperation and long-term
business relationship. Warmly your arrival to create a better
tomorrow.
