6# Wire CNC Control Hydraulic Wire Straightening And Cutting
Machine
Introduction of Wire Straightening and Cutting Machine
CNC Control Hydraulic Automatica Wire Straightening and Cutting
machine processing performance is strong, the wire diameter range
is large, the cutting length is no limited, high degree of
automation.Automatically set straightening and cutting length in
the visual touch screen, adopted with the safety device and
automatic counting and stop system. Mainly used for straightening
and cutting building cold-rolled steel wire and rebar, hot-rolled
steel wire, hot-rolled round steel wire and cold-rolled steel bar
etc.
Wire Straightening and Cutting Machine Feature
1. The wire material feeding is based on servo motor.Fast feeding
speed and high accuracy.
2. The straightening die is made of alloy with good quality and
wear resistance. It doesn't need to be replaced in seven or eight
years.
3. The machine is hydraulically cut off. 6mm diameter wire is very
easy to cut off. So this machine has a wide range of wire diameter.
Wire straightening and Cutting Machine Service
1. Maintenance period:one year
2. If the buyers need, we can send our technical staff to the
buyers’ place to debug the machine and providing the training in 30
days after the machines arrive at the destination port.
3. The commissioning fees: free
4. The training fees: The buyer need to pay
5. The numbers of technical persons: one technical person per
machines at most
6. The fees ,such as round-trip tickets, accomodation etc, are all
in buyers’ account. During the maintenance period: the parts
damaged non-artificially will be provided free of charge. If you
need the technicians, we will assign the expertised staff to your
company. And the fees,such as round-trip tickets, accomodation etc,
are all in your account. After the maintenance period: If you need
the machine parts, we will provide it as our cost. If you need the
technicians, we will assign the expertised staff to your company.
And the fees, such as round-trip tickets, accomodation etc, are all
in your account.
Wire Straightening And Cutting Machine Parameter
| Name | CNC hydraulic Wire straightening and cutting machine |
| Wire Diameter | 2.0-6.0mm |
| Input Voltage | 380V 50Hz ( Customized) |
| Steel wire surface | Galvanized wire,Black wire,Low carbon steel wire |
| Cutting Length | Customized |
| Tolerance of cut-to-length | ±1mm |
| Linearity of straightening | ≤2mm/m |
| Cutting Method | Hydraulic cut off |
| Max. straightening speed | 40 m / min |
| Weight | 350kg |
| Package | Wooden box |
Packaging and shipping
1. Packed in wooden case, or customized.
2. FOB Tianjin or other China main port by sea.
3. FOB Beijing airport or China main airport by air.
